PCIe-BaseLab
The Prototype Board for Designers of PCIe Hardware & Software Applications
Prototype board with PCI Express single-lane (x1) port:
- PCI Express Specification Revision 1.0 compliant,
- PCI Controller: PEX8311 (PLX Technology),
- Bus Master Transfer Mode, 2 DMA- Channels,
- universal parallel local Bus Interface, Data: 32/16/8Bit, Addresses: 32Bit,
- Local bus clock: up to 66MHz (feeding from external is possible),
- Daughter boards with large user area and/or SMD-Footprints will be available too.
more info

PCI-PROTO LAB/PLX-M
The Prototype Board for Designers of PCI Hardware & Software Applications.
- PCI Prototype Board,
- in compliance with PCI Local Bus Specification Rev2.2,
- PCI Controller: PCI9054 from PLX Technology,
- 32Bit/33MHz PCI, 3.3V, 5V tolerant,
- Bus Master Transfer, DMA,
- Universal local Processor Interface, Data: 32/16/8Bit, Addresses: 32Bit,
- On board EPLD: Lattice M4A3-64/32more info

PCIe Bus ExtenderThe ultimative tool for PCI Express Hardware Development
- allows safety and convenient tests of series and prototype cards
- offers true `Hot-Swap` function
- works with all common PCI Express card formats (x1, x4, x8, x16)
- safes the computer system for damages by test hardwaremore info

Pci Board Design Layout

Add-On Hardware Development for PCI Express /PCI-Systems
We specialize in developing add-on hardware for PCI Express, Standart PCI, CompactPCI, and Industrial PCI systems. Our expertise and capabilities are a result of our long-standing experience in computer development.As a team, involving the customer at every step, we can develop applications and solutions tailored towards the individual user's needs. We can develop and produce a range of solutions: from partial application development to complete and comprehensive solutions.
more info

Software Development
We can support you during the software development phase of your application. It might be driver and/or application development for the latest PCI systems technology, image processing, or other applications in the industrial testing or automation marketplace.
more info

Exciting Links
PLX Technology
Manufacturer of PCI9054 and other PCI controller devices.
PCISIG
PCI Special Interest Group
PCI Industrial Computer Manufacturers Group
PCI Industrial Computer Manufacturers Group
cpcitab
The Magazine for Developers of Industrial, Communication and Embedded PCI Systems.
DriverFactory, our Partner for hardware orientated software development

More Products of our Company HK Meßsysteme GmbH

Development Kit Contents

The PCI Development Kit, Cyclone II Edition features:
